How to Setup FortiClient IPSec VPN Client
SecureAX Managed Client Only
This section is intended for our managed IT clients. Please do not proceed unless explicitly instructed by your IT team. Modifying these settings without guidance may expose sensitive information or disrupt services.
Table of Contents
- Prerequisites
- Step 1: Launch FortiClient
- Step 2: Configure VPN connection
- Step 3: Connect to VPN
- Step 4: Disconnect
- Troubleshooting
Prerequisites
- FortiClient VPN installed on your device.
- VPN connection information
Step 1: Launch FortiClient
- Open FortiClient from your desktop or start menu.
- Click Configure VPN or Add a new connection.
- Click IPSec VPN.
- Enter the VPN details provided:
| Field | Example | Notes |
|---|---|---|
| Connection Name | Corp VPN |
Replace with your company name |
| Remote Gateway | vpn.company.com |
Refer to setup instructions |
| Pre-shared key | secret-passphase |
Refer to setup instructions |
| Authentication (XAuth) | username |
Optional |
| Single Sign On | Enable if instructed | For Microsoft 365 Authenicaton |
- Click Save or Apply.
Step 2: Connect to VPN
- Click Connect.
- Enter your username and password (and OTP if required).
- Wait for Connected status to appear.
- Verify connectivity by accessing internal corporate resources (e.g., intranet or shared drives).
Step 3: Disconnect from VPN
- Click Disconnect.
- Close FortiClient if you do not need it running.
Troubleshooting
| Issue | Solution |
|---|---|
| Cannot connect | Check Internet connection, server address, and credentials. |
| Two-Factor prompt fails | Verify time on your device matches authenticator app. |
| Connection drops | Reconnect or contact IT support. |
